560 Model Sawdust Straw Wood Pellet Making Pellet Mill Machine With 1-2 T/H Capacity

560 Model Sawdust Straw Wood Pellet Making Pellet Mill Machine With 1-2 T/H Capacity

Product Description


The new biomass pellet machine is a device that recycles wood chips, corn stalks, shavings, bark and waste materials from wood factories. Through this equipment, it is processed into pellet fuel for combustion. Our Biomass pellet machine effectively solves the shortcomings of difficult granulation and poor effect on crude fibers such as straw. The molded pellet fuel has the characteristics of high fuel value, high density and easy transportation. The volume of the formed particles is 1/8 of the volume of the raw material, the density is 0.8-1.5, and the calorific value can reach 3400-6000 kcal. Biomass pellet machine is a new type of bio-energy equipment, which effectively handles various waste materials-biomass pellet machine.

WORKING PRINCIPLE
The following conditions should be met before granulation:

1: The granulation material needs to be sawdust-like, and if the material is large, it needs to be processed by a chipper or a pulverizer before processing.

2: The moisture content of the granulation material must be between 10-15%. If the moisture content is too high, use a three-cylinder dryer or a single-cylinder dryer for drying.
The biomass pellet machine (ring mold) adopts two-stage transmission of belt and worm gear; the feeding depends on the gravity of the material itself, and is adsorbed on the conveyor belt to realize feeding; at the same time, the equipment is also equipped with dust removal equipment, which can effectively remove the dust generated by the equipment; we have also increased the compactness of the product, which greatly reduces the noise and wear of parts during the operation of the machine.

3. The pulverized material enters the inside of the pellet machine through the feed port, and the inside is composed of two rotating turbines. Through the rotation, the material is extruded into a solid state, and then discharged from the outer mold hole to achieve a granular shape.
Application Of Wood Pellet Mill:

It is mainly suitable for coarse fiber granulation, such as: sawdust, rice husk, cotton stalk, cottonseed husk, weeds and other crop straws, domestic garbage, factory waste, granulation of materials with low bonding rate and difficult to form, It can be applied to low-temperature granulation of biological bacterial fertilizer, organic fertilizer, compound fertilizer, etc. It can also be used for pressing and granulating various feeds.

Technical Parameters










 Main Performance Characteristics:
1. Equipped with a heavy-duty reducer to effectively extend the life of the equipment.
2. Both ends of the finale shaft of this model are consistent with the linear speed of the inner and outer rings of the die plate, and there is no dislocation friction between the wheel and the die, which reduces resistance, reduces kinetic energy loss, and prolongs the service life of the abrasive tool.
3. The finale is set evenly and runs smoothly.
4. The central pressure regulating structure is adopted to adapt to different materials and ensure the pressing effect. The compression molding of sawdust [sawdust], corn stalks, and crop stalks requires a lot of pressure. The central part of similar granulation equipment is made of high-quality alloy steel, which improves the service life of the wheel.
5. The template of this structure is stationary, and the main shaft drives the pressing wheel to press the material, which is suitable for pressing difficult-to-press particles.
6. This model is equipped with 3-30mm various hole diameter molds, which are suitable for granulation of different materials
